Kolibrik potentiostat 520

Code ID: 155M

Product Description

The Kolibrik potentiostats, deliver precise and reliable electrochemical measurements for research, ...

Read more
Dimensions / mm19“ rack-mount, 4U; 440 (W) × 177 (H) × 358 (D)
Compliance - Output voltage / V
Compliance - Output current / V
Max. internal power dissipation / W
Current ranges
Sampling14-bit ADCs, up to 20 Msps for EIS measurements, max. 2000 samples per single frequency
AccuracyVoltage: ≤ 0.1% of range + 0.1% of reading Current: ≤ 0.1% of range + 0.5% of reading
EIS frequency1 mHz ... 100 kHz, limited use up to 1 MHz
EIS amplitude (for < 1 kHz)

Query

How does the Inquiry List work?

Acquitions methods

  1. Constant V, I
  2. Open circuit,
  3. Manual control
  4. Linear Sweeps
  5. Cyclic Voltammetry
  6. Cyclic Amperometry
  7. Potentiostatic and Galvanostatic Electrochemical Impedance Spectroscopy (EIS)
  8. Battery Charging and Discharging (CC-CV)
  9. Chronoamperometry
  10. Chronopotentiometry
  11. Double-step Chronoamperometry and Chronopotentiometry
  12. Square Pulse Potentiometry and Amperometry
  13. Current interrupt
  14. Python scripting
